TFT LCD Display Module

Showing 10–18 of 75 results

15.6 inch FHD 1920*1080 LVDS Interface TFT LCD Panel Module
Keyword: TFT LCD Panel
Size: 15.6 inch lcd panel
Resolution: 1920*1080
Pin: 40pin

Product Features
-FHD Resolution (1920 * 1080)
-Very High Contrast Ratio: 3000:1
-Ultra Wide Viewing Angle: 178°(H)/178°(V) (CR10)
-DE (Data Enable)Mode
-LVDS (Low Voltage Differential Signaling) Interface

With HDMI Board

Interface: LVDS, EDP

Pin: 30pin, 40pin

Resolution: 1920*1080, 1366*768

Click→1.3″-10.1″ LCD Panel List

Click→10.2″-24″ LCD Screen List

Click→Round LCD Display List
17 inch TFT LCD 1280*1024 Display Panel
Model: DV170E0M-N10
Size: 1280*1024
Active area: 345.408(H) × 259.056(V)mm
Interface: LVDS
Features
- LVDS interface with 2 pixel / clock
- High-speed response
- Low color shift image quality
- 6-bit+FRC color depth, display 16.7M colors
- Wide viewing angle
- DE (Data Enable) only mode
- IHADS technology is applied for high display quality
- RoHS compliany
With HDMI Board

Custom LCD Control Board
18.5 inch LCD Panel 1920*1080 Color TFT LCD Module
Name: 18.5 inch LCD Panel
Resolution: 1920*1080
Interface: LVDS
Pin: 30pin

Features
* LED back-light
* LVDS interface
* RoHS Compliant
* 16.7M color depth

Resolution: 192081080
Interface: LVDS
Pin: 30pin
19 inch TFT LCD Screen 1280*1024 IPS LCD Display Panel
Model: MV190E0M-N10
Size: 19 inch TFT LCD Module
Resolution: 1280*1024
Interface: LVDS
Features
- LVDS Interface with 2 pixel / clock
- High-speed response
- 6-bit (Hi-FRC) color depth, display 16.7M colors
- High luminance and contrast ratio, low reflection and wide viewing angle
- DE (Data Enable) only
- RoHS/Halogen Free (except connector )
- Gamma Correction
- Reverse type
Application
- Desktop Type of PC & Workstation Use

  Slim-Size Display for Stand-alone Monitor

  Display Terminals for Control System

  Monitors for Process Controller
With HDMI Board

Customized

1.3″-10.1″ TFT LCD List

10.2″-24″ TFT LCD List

Round TFT LCD Display List

Sunlight Readable LCD Display List
2 inch LCD Module 320*240 TFT Display
Model: RV020QVM-300-12
Size: 2 inch lcd display
Resolution: 320*240
Interface: SPI
- Size: 2 inch lcd module
- Resolution: 320*240
- Brightness: 300nit
- Interface: SPI
- IC Driver: ILI9342
Support
- With HDMI board
- Custom Touch
- Custom brightness
- Get LCD board support
2.8 inch 240*320 IPS TFT LCD Display Module with CTP
Model: RV028QVP-350-10
Size: 2.8 inch
Resolution: 240*320
Interface: SPI
Square 2.8 inch 240*320 TFT LCD Panel
- LCD AA: 43.2 (H)* 57.6 (V)
- TP VA: 43.6 (H)* 58.05 (V)
- Driver IC: ST7789
- Touch IC: FT6336U
- Interface: SPI
- Touch structure: G+F
- Surface hardness: 6H
- with touch
21.5 inch FHD 1920*1080 TFT LCD Panel Desktop LCD Display
Size: 21.5 inch TFT LCD Display
Resolution: 1920*1080
Interface: LVDS
Surface Treatment: Anti-glare, 3H
- Size: 21.5 inch TFT LCD Display
- Resolution: 1920*1080
- Interface: LVDS
- Surface Treatment: Anti-glare, 3H
- Display mode: Normally Black
21.5 inch LCD Panel 1920*1080 TFT LCD Screen
Model: RV215FHM-300-30
Size: 21.5 inch TFT LCD Panel
Resolution: 1920*1080
Brightness: 300nit/500nit
- Size: 21.5 inch TFT LCD Panel
- Resolution: 1920*1080
- Brightness: 300/500 nit
- Display Mode: Normally Black(IPS)
- Display area: 478.656(H) x 260.28 (V)
- Outline Dimension: 495.64(H) x 292.21(V) x9.85(D)
- Interface: LVDS
With HDMI Board

With LCD Control Board

Custom Brightness

Custom LCD Control Board

Get more LCD solution
3.2 inch LCD Display 1024*768 LCD Module
Model: RV032WSM-500-30
Resolution: 1024*768
Driving IC: JD9168
Interface: MIPI
- Size: 3.2 inch LCD Display
- Resolution: 1024*768
- Interface: MIPI
- Brightness: 500 nit
- Driving IC: JD9168
Support
- HDMI board
- Custom touchscreen/interface/brightness
- LCD Control board such as Android board
