7-Inch Capacitive Touch Display – 1024×600 Resolution, with HMI Motherboard
- 7-Inch TFT LCD: The display boasts a 1024×600 resolution, delivering clear and vibrant visuals suitable for various applications, from industrial control panels to consumer devices.
- Capacitive Touch Interface: Supports multi-touch functionality, ensuring smooth and responsive interaction, essential for modern user interfaces.
- ZDP14X0 Display Driver: This powerful chip supports RGB/MIPI interfaces, enabling high-resolution display up to 1920×1080. It integrates 16/64MB of display memory, a 2D graphics accelerator, and MJPEG decoding, making it ideal for complex graphics and video processing.
Share your interface, touch, brightness and volume requirements for an engineering fit review.
Product overview
Engineered for application fit
The RJYZN07000009 HMI motherboard, paired with a 7-inch 1024×600 capacitive touch display, offers an advanced solution for developers seeking a high-performance platform for interactive embedded systems.
Display and Touch Features
- 7-Inch TFT LCD: The display boasts a 1024×600 resolution, delivering clear and vibrant visuals suitable for various applications, from industrial control panels to consumer devices.
- Capacitive Touch Interface: Supports multi-touch functionality, ensuring smooth and responsive interaction, essential for modern user interfaces.
Hardware Highlights
- ZDP14X0 Display Driver: This powerful chip supports RGB/MIPI interfaces, enabling high-resolution display up to 1920×1080. It integrates 16/64MB of display memory, a 2D graphics accelerator, and MJPEG decoding, making it ideal for complex graphics and video processing.
- Comprehensive Interfaces:
- RGB Interface: 50-pin, 0.5mm connection for seamless display integration.
- Touch Panel Interface: 6-pin, 0.5mm I2C interface for the capacitive touch sensor.
- Debug Serial Interface: 4-pin, 2.54mm interface for easy debugging during development.
- Additional Features: Includes a 5V passive buzzer, SD card slot, speaker interface, DC power input (12-48V), 128MB NOR Flash for storage, RTC with I2C interface, RS485 communication, USB port for firmware updates, and SPI communication interface.
Versatile Applications
This motherboard and display combination is ideal for a wide range of applications:
- Industrial Automation: Act as an interface for machinery control and monitoring.
- Home Automation: Serve as a central control hub for smart home devices.
- Medical Devices: Provide an intuitive touchscreen interface for healthcare monitoring equipment.
- Retail Kiosks: Power interactive kiosks for enhanced customer engagement.
- Automotive Systems: Integrate into car dashboards for infotainment and vehicle control.
- Fitness Equipment: Manage user interfaces on gym equipment such as treadmills.
- Smart Appliances: Embedded control panels for modern home appliances.
- Public Information Systems: Use in digital signage and information kiosks.
